Axim RE-700 Extension Rod with Coupler

Axim RE-700 extension rod with coupler for the Axim PR-7000 series concealed rod panic exit devices. The extension rod is used on taller-than-standard doors where the standard top rod length is insufficient to reach the top strike — required on doors taller than 2135mm. The coupler connects the extension rod to the existing standard rod, extending its reach without replacing the full device.

Key Features

• For use with Axim PR-7000 series panic exit devices
• Required on doors taller than 2135mm
• Available in 300mm and 600mm extension lengths
• Coupler included — connects to existing standard rod

Selecting the Right Length

Measure the door height and subtract 2135mm — the result is the minimum extension required. Select the 300mm rod if the additional length needed is 300mm or less; select the 600mm rod for taller doors. If the door exceeds 2735mm, contact us as a double extension may be required.

Compatible Devices

• Axim PR-7085 Concealed Rod Crash Bar Exit Device
• Axim PR-7085P Concealed Rod Paddle Exit Device
• Axim PR-7100 Concealed Touch Bar Exit Device

Download the Axim Technical Manual (PDF)
